If you are improving your outlets or wiring, you may plan on doing electrical panel upgrades, too. If you’re wondering, “What type of breaker do I need?” you’re not alone; plenty of people consider this question when they begin the process. Learn more about this topic and how to find the option that’s compatible with your needs.
How To Tell What Type of Breaker I Need
If you are wondering which type you need, start by thinking about what sorts of appliances you’ll use. From there, you can pick from the following options.
Standard Circuit Breakers
Standard options are available in single- and double-pole designs.
A single-pole breaker has one hot wire and one neutral wire. The double-pole breaker has two hot wires that share the same neutral wire.
Double-poles can handle higher amps, while single-poles are limited to up to 30 amps. If you know you’ll be using devices that require higher energy loads, use the former.
GFCI Circuit Breakers
A GFCI is the right option to use for wiring that may have water exposure. Install one of these for areas like:
- Kitchens
- Bathrooms
- Laundry rooms
- Basements
AFCI Circuit Breakers
An AFCI has an extra safety feature that detects a sudden electrical surge (or an arc) and cuts the power. The AFCI detects power overloads faster than other types. Because of this, these work great for people searching for extra safety.
The National Electrical Code (NEC) may require installing AFCIs in new construction or when remodeling existing electrical systems. Make sure to check your local codes before proceeding.
Specialty Circuit Breakers
In a commercial or industrial setting, you might want specialty breakers, including:
- Thermal
- Hydraulic
- Magnetic
Specialty circuits measure specific changes in the electrical load that allow it to trip and interrupt the power flow faster than other designs. Early detection may be vital for protecting delicate industrial equipment and machinery.
How To Manage Your Electrical Load Requirements
Reliable electronics and breakers for your building’s power system are the keys to managing load requirements safely. Learn more about using the right options for different power loads.
What Type of Breaker Do I Need for 220v?
The electrical code requires the use of a double-pole option. The double-pole can handle the higher voltage found in appliances that use a 220v circuit, including:
- Clothes dryer
- Electric stove
- Air conditioner
What Type of Circuit Breaker Do I Need for 120v?
You’ll usually use a single-pole for this output. This is especially common in residential electrical panels, where the breakers are rated for 120 volts and 15 or 20 amps.
